EcoGrid Biaxial
EcoGrid BIAXIAL
Material sintetis berbentuk jaring) yang memberikan perkuatan dua arah (membentuk lubang persegi) untuk stabilisasi dan perkuatan tanah dasar.
EcoGrid Biaxial
Solusi Perkuatan Tanah Dua Arah
Material geosintetik berbentuk lembaran jaring dengan bukaan berbentuk bujur sangkar atau persegi panjang. Produk ini dirancang khusus untuk memberikan perkuatan dua arah (biaxial reinforcement), baik secara memanjang maupun melintang, sehingga mampu meningkatkan stabilitas, daya dukung, serta kekakuan tanah dasar yang lemah. Dengan prinsip interlocking, EcoGrid biaxial bekerja mengikat partikel agregat pada lapisan timbunan, mendistribusikan beban secara lebih merata, serta mengurangi risiko penurunan diferensial (differential settlement) pada tanah lunak.
Fungsi Utama
- Stabilisasi Tanah Dasar
- Mencegah penurunan tidak merata pada area dengan tanah lunak seperti rawa, gambut, atau lahan berair.
- Perkuatan Timbunan
- Meningkatkan kekakuan serta daya dukung tanah timbunan sehingga konstruksi lebih stabil.
- Distribusi Beban Merata
- Menyebarkan beban dari lapisan permukaan ke tanah dasar di bawahnya, mengurangi tekanan berlebih pada tanah lemah.
- Efisiensi Biaya Konstruksi
- Mengurangi kebutuhan ketebalan base course atau sub-base hingga ±40%, sehingga lebih ekonomis.
Cara Kerja
- Interlocking (Mengunci Agregat)
Partikel agregat masuk ke dalam lubang EcoGrid dan terkunci, sehingga lapisan menjadi lebih stabil. - Meningkatkan Kekakuan Lapisan
- Ikatan antar agregat yang terkunci membuat lapisan timbunan lebih kaku, padat, dan tahan deformasi.
Material Bahan
Ecogrid biaxial diproduksi dari polimer berkualitas tinggi yang tahan lama, di antaranya:
- Polypropylene (PP)
- High Density Polyethylene (HDPE)
- Polyester (PET)
Bahan ini memiliki ketahanan tinggi terhadap tarikan, cuaca, dan lingkungan agresif.
Ciri Khas EcoGrid Biaxial
- Bukaan Jaring: berbentuk bujur sangkar/empat sisi.
- Perkuatan Dua Arah: efektif menahan beban baik arah longitudinal maupun transversal.
- Ringan dan Fleksibel: mudah dipasang di berbagai kondisi lapangan.
- Tahan Lama: awet terhadap kimia tanah, air, dan mikroorganisme.
Technical Data Sheet (TDS)
Factory Quality Certificate
After testing, the PP Biaxial Geogrid (batch number LY-20230208) provided by our company has the specification model 25-25KN, which conforms to the GB/T17689-2008 standard implemented by our company. After sampling inspection by our company’s quality inspection department, the product is qualified and agreed to leave the factory (with the inspection report attached).
EcoGrid
Biaxial PP 25 KN / 25 KN
Product test items and results
| Product name | PP Biaxial Geogrid | Specification | 25-25KN |
| Production workshop | Geogrid workshop | ||
| Sampling inspection | 张衍伟 | Production team | The first team |
| Inspection date | 20230208 | Inspection equipment | Electronic testing machine, etc. |
| Number | Test item | Unit | Standard values | Experimental values | Individual assessment |
|---|---|---|---|---|---|
| 1 | MD Tensile strength | KN/m | ≥25 | 25.9 | Qualified |
| 2 | CD Tensile strength | KN/m | ≥25 | 25.8 | Qualified |
| 3 | MD Break Elongation | % | ≤15 | 12.6 | Qualified |
| 4 | CD Break Elongation | % | ≤13 | 11.8 | Qualified |
| 5 | MD Tensile Strength at 2% strain | KN/m | 9.0 | 11.1 | Qualified |
| 6 | CMD Tensile Strength at 2% strain | KN/m | 9.0 | 11.2 | Qualified |
| 7 | MD Tensile Strength at 5% strain | KN/m | 17.0 | 21.9 | Qualified |
| 8 | CMD Tensile Strength at 5% strain | KN/m | 17.0 | 21.5 | Qualified |
| Comprehensive evaluation | The comprehensive evaluation of this product meets the requirements of GB/T17689-2008. It is judged as qualified product. | ||||
Technical Data Sheet (TDS)
EcoGrid
Biaxial 30 KN / 30 KN
Product test items and results
| Product name | PP Biaxial Geogrid | Specification | 30-30KN |
| Production workshop | Geogrid workshop | ||
| Sampling inspection | 张衍伟 | Production team | The first team |
| Inspection date | 20230824 | Inspection equipment | Electronic testing machine, etc. |
| Number | Test item | Unit | Standard values | Experimental values | Individual assessment |
|---|---|---|---|---|---|
| 1 | MD Tensile strength | KN/m | ≥30 | 25.9 | Qualified |
| 2 | CD Tensile strength | KN/m | ≥30 | 25.8 | Qualified |
| 3 | MD Break Elongation | % | ≤15 | 12.6 | Qualified |
| 4 | CD Break Elongation | % | ≤13 | 11.8 | Qualified |
| 5 | MD Tensile Strength at 2% strain | KN/m | 10.5 | 11.1 | Qualified |
| 6 | CMD Tensile Strength at 2% strain | KN/m | 10.5 | 11.2 | Qualified |
| 7 | MD Tensile Strength at 5% strain | KN/m | 21.0 | 21.9 | Qualified |
| 8 | CMD Tensile Strength at 5% strain | KN/m | 21.0 | 21.5 | Qualified |
| Comprehensive evaluation | The comprehensive evaluation of this product meets the requirements of GB/T17689-2008. It is judged as qualified product. | ||||
Technical Data Sheet (TDS)
EcoGrid
Biaxial PP 40 KN / 40 KN
Product test items and results
| Product name | PP Biaxial Geogrid | Specification | 40-40KN |
| Production workshop | Geogrid workshop | ||
| Sampling inspection | 张衍伟 | Production team | The first team |
| Inspection date | 20240324 | Inspection equipment | Electronic testing machine, etc. |
| Number | Test item | Unit | Standard values | Experimental values | Individual assessment |
|---|---|---|---|---|---|
| 1 | MD Tensile strength | KN/m | ≥40 | 41.9 | Qualified |
| 2 | CD Tensile strength | KN/m | ≥40 | 40.8 | Qualified |
| 3 | MD Break Elongation | % | ≤15 | 12.6 | Qualified |
| 4 | CD Break Elongation | % | ≤13 | 11.8 | Qualified |
| 5 | MD Tensile Strength at 2% strain | KN/m | 10.5 | 11.1 | Qualified |
| 6 | CMD Tensile Strength at 2% strain | KN/m | 10.5 | 11.2 | Qualified |
| 7 | MD Tensile Strength at 5% strain | KN/m | 21.0 | 21.9 | Qualified |
| 8 | CMD Tensile Strength at 5% strain | KN/m | 21.0 | 21.5 | Qualified |
| Comprehensive evaluation | The comprehensive evaluation of this product meets the requirements of GB/T17689-2008. It is judged as qualified product. | ||||
Kesimpulan:
EcoGrid Biaxial PP memberikan keunggulan pada stabilisasi tanah, distribusi beban yang lebih seimbang, serta penghematan biaya, sehingga menjadi solusi andalan untuk berbagai proyek di atas tanah lunak, mulai dari jalan, rel kereta, pelabuhan, hingga reklamasi.
